Shop drawings for construction vs. design drawings: comparative
What are shop drawings
Shop drawings are detailed, project-specific documents that are mostly prepared by contractors, fabricators, or suppliers to guide the manufacturing, assembly, and installation of certain components in a construction project. If you’re wondering how these differ from general design drawings—which are usually produced by architects or engineers—it’s important to know that shop drawings focus on how each part will actually be fabricated and installed, based on the specific needs of the project. These drawings typically follow the general intent of the design documents but go a step further by giving the exact details that construction or fabrication teams need to get the job done right. Here in the United States, shop drawings are required for things like steel structures, concrete reinforcement, mechanical systems, and all kinds of custom architectural elements.
It’s worth considering that shop drawings are a critical part of the submittal process in U.S. construction. You’ll see this in standard contract documents, like those from the American Institute of Architects (AIA). Basically, they serve as the bridge between design intent and actual construction, turning architectural and engineering ideas into actionable instructions for the people working on site. Take a steel staircase, for example: the shop drawings for that staircase will show all the fabrication details, weld types, bolt sizes, and the step-by-step installation sequence, so the manufacturer and installer can deliver a safe and code-compliant product. Shop drawings are also needed for things like prefabricated components, modular assemblies, HVAC ductwork, electrical panels, and other custom or complex systems.
What information is included in shop drawings
Shop drawings are packed with comprehensive and precise information that’s tailored to what fabricators and installers really need. You’ll usually find:
Dimensions
Materials
Fabrication details
Installation instructions
References to specific building standards or codes
Some of the most important information includes:
Material specs
Welding and joining details
Finishes
Hardware requirements
Exact layout of the elements
Notes about tolerances and connection methods
Coordination with other trades or building systems
Something you should keep in mind is that shop drawings often highlight any changes or deviations from the original design drawings, and they must get the green light from the design team or the owner’s representative before any fabrication begins. In the U.S., these documents generally have to meet standards set by groups like the AIA and the Construction Specifications Institute (CSI).
In addition, shop drawings might include:
Schedules
Diagrams
Manufacturer’s installation guidelines
For example, if you’re dealing with structural steel, the drawings will show detailed connection types, bolt patterns, and the proper assembly sequence. For curtain wall systems, you’ll see glazing types, anchor locations, and water management details. Color codes, finish types, and surface treatments are also included—especially when appearance or durability is a big deal. Shop drawings often reference national standards, like those from the American Welding Society (AWS) or ASTM International, to make sure everything’s up to industry best practices. If the project involves federal contracts, shop drawings also need to line up with the Federal Acquisition Regulation (FAR) section 52.236-21, which sets the rules for shop drawing submittals and approvals.
Who uses this type of drawings
Shop drawings are mainly used by professionals who are directly involved in the fabrication and installation of building components, such as:
Contractors
Subcontractors
Manufacturers
Suppliers
Project managers and construction superintendents also rely on these drawings to coordinate work, schedule deliveries, and double-check that everything meets the project requirements. Architects and engineers review and approve shop drawings to make sure they align with the original design intent and comply with codes like those from the Construction Specifications Institute (CSI) and federal standards such as FAR 52.236-21. Sometimes, owners or their representatives are also part of the review and approval process.
Other uses include:
Fabricators using shop drawings as a guide for producing structural steel, precast concrete, millwork, and custom components
Installers and field crews depending on these drawings for accurate placement and assembly
Owners and construction managers verifying that proposed materials and methods meet contract requirements and maintaining records for future maintenance or renovations
For complex projects—think hospitals or high-rise buildings—coordination between different trades is a big deal. Shop drawings help by providing a clear record of each system’s requirements and how they fit into the overall construction.
Software that assists in the process of drawings for steel structures
When it comes to developing shop drawings for steel structures, specialized software tools play a huge role in handling the complexity and accuracy needed for fabrication and installation. Some of the most popular platforms in U.S. construction are:
Autodesk AutoCAD
Autodesk Revit
Tekla Structures
SDS/2
These programs make it possible to:
Create detailed 2D and 3D models
Catch design clashes early
Coordinate through Building Information Modeling (BIM) workflows
BIM is especially important these days—it boosts accuracy, reduces errors, and makes communication among project stakeholders smoother. Plus, these software solutions connect with other project management and fabrication systems, helping you keep shop drawings in sync with the latest design changes and construction schedules.
For example:
Tekla Structures is widely used for structural steel detailing because it can generate highly accurate 3D models and automate the creation of fabrication drawings, material lists, and even CNC data for manufacturing equipment.
Autodesk Revit is key for BIM coordination, letting steel detailers work in the same model as architects and engineers, which helps reduce conflicts and leads to better results.
SDS/2 offers automated connection design and code compliance checks, saving time and cutting down on manual errors.
Many of these tools come loaded with libraries of standard connections, parametric components, and integration features that make collaboration between architects, engineers, and fabricators much easier. As construction projects get more complex, the use of digital twins and cloud-based collaboration platforms has made shop drawing production and review even more efficient and accurate.
Differences between shop drawings and design drawings
Shop drawings and design drawings each play a unique role in the construction process, and it’s important to understand how they’re different.
| Aspect | Design Drawings (Construction Documents) | Shop Drawings |
|---|---|---|
| Prepared by | Architects, Engineers | Contractors, Fabricators, Suppliers |
| Purpose | Show overall intent, layout, compliance | Detail fabrication and installation |
| Scope | Broad (entire project) | Specific (individual components) |
| Content | Concepts, dimensions, materials, codes | Tolerances, welds, hardware, sequences |
| Approval | Regulatory review, permits | Design team, contractors, sometimes owners |
| Standardization | AIA, CSI symbols and notations | May include proprietary info and methods |
| Legal Status | Part of contract documents | Submittals, not contracts |
Design drawings are usually issued in sets that cover architecture, structure, mechanical, electrical, and plumbing. They use standardized symbols, scales, and notations set by organizations like the AIA and CSI. These documents are key for getting permits and for communicating the project’s vision to everyone involved.
Shop drawings, by contrast, often include proprietary info, fabrication methods, and installation sequences that are unique to the manufacturer or installer. For example, a design drawing might specify where a window wall system goes and what its dimensions are, but the shop drawing will show the exact extrusion profiles, fastener types, and waterproofing details needed for fabrication and installation.
Comparison between shop drawings and design drawings
If you look at them side by side, the differences between shop drawings and design drawings become pretty clear.
Design drawings lay the foundation for the project, giving a full overview of architectural, structural, and system requirements. They communicate the vision and intent of the design professional and make sure everything is up to code, following standards set by groups like the American Institute of Architects (AIA) and the Construction Specifications Institute (CSI).
Shop drawings take that general design intent and turn it into detailed instructions for fabrication and installation. They come into play after the design drawings are released and often have their own separate review process. The level of detail in shop drawings is much higher, addressing real-world challenges like site conditions, material availability, and coordination with other trades.
For example, a design drawing might show where a structural steel column should go and its dimensions, but the shop drawing will give you the exact fabrication details, connection methods, and the step-by-step installation sequence for that column.
Both types of drawings are essential for a successful construction project here in the U.S. Design drawings get the process started and set the parameters, while shop drawings make sure every component is built and installed just right. Clear communication and coordination between the two help prevent mistakes, cut down on rework, and keep the project on schedule.
In real-world practice, this often means going through several rounds of review: after shop drawings are submitted, the design team checks them to make sure they match the design intent, and then notes any changes that need to be made. It’s not unusual for this process to involve multiple revisions before final approval.
It’s also worth noting that the distinction between these two types of drawings matters for risk management and contracts. Design drawings are usually part of the contract documents and serve as the legal foundation for the project, while shop drawings are considered submittals—they have to comply with the contract documents, but they aren’t contracts themselves. You’ll often see these differences spelled out in standard AIA contract forms and the Construction Specifications Institute’s Project Delivery Practice Guide.
Examples of design drawings for aluminum structures
Design drawings for aluminum structures are especially important in projects that feature specialized architectural elements like curtain walls, storefront systems, and exterior facades. These documents lay out the overall geometry, support conditions, load requirements, and how the system integrates with the rest of the building. For instance, if you’re looking at a design drawing for an aluminum curtain wall system, you’ll see things like elevations, sections, and connection details showing how everything fits with structural components and building finishes.
When it comes to aluminum cladding, design drawings will specify panel sizes, joint details, anchorage methods, and waterproofing requirements. These drawings are essential for fabricators and installers to fully understand what the architect wants and to ensure that the final installation looks good and performs well. Coordinating with shop drawings is key here, since shop drawings will refine details like panel attachment hardware, field measurements, and any adjustments needed for site conditions. The use of BIM and advanced CAD software makes it even easier to get both design and shop drawings for aluminum structures right, especially in U.S. construction projects.
A common example is the design and installation of aluminum cladding systems, which you’ll see on a lot of commercial and institutional buildings. The design drawings will show the overall pattern, dimensions, and attachment points for the cladding panels, as well as how they relate to windows, doors, and other façade elements. You might also find performance criteria like wind load resistance, insulation values, and compliance with energy codes. Shop drawings for aluminum cladding will then break down the panel fabrication details, including cut lists, fastener locations, and sealant requirements, making sure every panel fits perfectly and does its job.
If your project is aiming for sustainability, like LEED certification, design drawings might also include requirements for recycled content, finish types, and other environmental criteria for aluminum components. The coordination between design and shop drawings becomes even more important when you’re dealing with custom finishes, complex shapes, or proprietary systems from manufacturers. By using advanced modeling tools and sticking to industry standards, teams can deliver high-performing, visually appealing aluminum structures, all while minimizing errors and keeping construction on track. If you’re interested in learning more about aluminum cladding and how it fits into modern construction, you might want to check out the resources available at Aplank.
